HORIZONTAL BENDING CENTER WS42
Apr 30, 2022|
Horizontal CNC steel bar bending center is mainly used in national infrastructure construction fields such as railways, highways, bridges, tunnels, underground pipe corridors, etc., especially for the bending of bar steel bars in box beams and cover beams. The equipment is mainly for φ12-40 rebar processing, mainly for the one-time forming processing of large cover beam steel bars and box beam steel bars. It is suitable for one-time forming processing of bar steel bars in box beams and cover beams. Model Processing diameter Φ12-40mm Bending speed 45-60°/s Moving speed 0.5-0.9m/s Bending angle Forward bend 0-180° Reverse bend 0-120° Installed power 27Kw Max conveying roller support 1000Kg shortest bending length 950mm longest bending length 11000mm L*W*H 12.8mx3mx1.1m Weight 6.5t Bending capacity Dia Φ 12 14 16 18 20 22 25 28 32 40 Pcs 6 5 5 4 3 3 2 1 1 1 The left and right bending heads and grippers are equipped with automatic rebar unloading hooks to realize automatic unloading of long rebar processed steel bars. The walking mechanism of the bending center head adopts a thickened rack, with rigid feet, and the walking positioning is more accurate and stable. The rebar gripper adopts a double-acting cylinder, which ensures that the left and right sides are clamped at the same time when gripping the rebar. When changing the rebar specification, there is no need to adjust the gripper. The operating system is equipped with a powerful database, which can store more than 300 kinds of graphics. For large arcs and incrementally changing ribs, all can be set with one key, and there is no need to manually input parameters each time. |END|
WS42
