GUTE Rebar Feeding Machine 15KW Feeding Robot 12*2.8*1.6m
Jun 29, 2022| Overview
The CNC automatic rebar feeding machine is a machine and equipment that automatically divides and feeds materials. This machine only needs one button to select the corresponding number of rebars and rebar diameters on the touch screen, and automatically completes the adjustment distance of the movable ladder rubbing plate. After starting, the rebar After the cam distributing mechanism, the staggered steel bars are straightened out, and then sent to the stepped rolling mechanism to complete automatic feeding, one by one, when the number of steel bars required for the setting is reached, the steel bars are automatically fed to the configured machinery and equipment.
Scope of application
Mainly used in the construction of high-speed, road and bridge, railway, subway and other projects.
Device parameters
| Rebar diameter | Φ12-φ40mm |
Feeding speed | 16次/min |
Rebar length | ≦12m |
| rated power | 15KW |
Total Weight | 2.6T |
| Overall size | 12*2.8*1.6m |
Equipment advantages
Cam material distributing mechanism: Automatically disperse materials, disperse raw materials and disordered steel bars, and automatically disperse materials;
Ladder rubbing board feeding mechanism: automatic quantitative feeding and distributing purpose according to system control;
Quantitative feeder: one-key operation, automatic distance adjustment, to achieve the purpose of automatic quantitative feed, according to the control system, control the quantity, and carry out the purpose of feed.
