Steel Rod Cutter

Features (GQ42D):
Cutting Diameter: 6-40mm
Blade Type: moon shape
Motor Power: 3kw-2p
Cutting Speed: 48T/min
Working Disc Speed: 15r/min
Weight: 340kg

Product Details


1. Used for cutting plain round bar and ribbed rebar, also can cut flat bar, square bar and angle bar.

2. Small size, light weight, compact structure, solid and reliable.

3. Good lubricating with gears splash.

4. Little power lose with antifriction bearing, small resistance

5. It’s convenient to be moved and done maintenance.


STEEL BAR CUTTER GQ42D

CUTTING CAPACITY

6-40 mm (ob ≤450N/mm2)

6-36 mm (ob ≤650N/mm2)

FLAT STEEL

70 x 15 mm



ANGLE STEEL

50 x 50 mm



TYPE OF MOTOR

Y2 100L-2



MOTOR POWER

3 KW-2P



MOTOR SAFETY

IP44, IP54, IP55



MOTOR ROTATION SPEED

2860 R/min



CUTTING SPEED

48 T/min



WEIGHT

495 Kg.



EXTERNAL DIMENSIONS

1100*500*900 mm



CERTIFICATION

2006/42/EC - 2006/95/EC / ISO 9001:2008
