Automatic Bar Cutting Machine

Features (GQ42D-1):
Cutting Diameter: 6-40mm
Blade Type: moon shape
Motor Power: 3kw-2p
Cutting Speed: 48T/min
Working Disc Speed: 15r/min
Weight: 340kg

Product Details


•GQ42D adopts GEARS, SHAFTS, CONNECTION ROD and BLADES made of high-quality alloyed steel with required heat treatment (quenching/ tempering/ high frequency) and 15mm thick external case to ensure reliable performances also under heavy loads and long working life.

•CONNECTION ROD has high hardness degree on attaching part with the blade, its internal side is made of tin-bronze to avoid abrasions while touching the crankshaft.

•Thick BLADES (4 edges) to ensure accurate cutting with all kinds of steel bar (square blade or moon-shape blade option with press-spring).

•CE Certificated dust proof MOTOR with aluminium shell.

•CE Certification (2006/42/EC - 2006/95/EC).


STEEL BAR CUTTER GQ42D

CUTTING CAPACITY

6-40 mm (ob ≤450N/mm2)

6-36 mm (ob ≤650N/mm2)

FLAT STEEL

70 x 15 mm


ANGLE STEEL

50 x 50 mm


TYPE OF MOTOR

Y2 100L-2


MOTOR POWER

3 KW-2P


MOTOR SAFETY

IP44, IP54, IP55


MOTOR ROTATION SPEED

2860 R/min


CUTTING SPEED

48 T/min


WEIGHT

495 Kg.


EXTERNAL DIMENSIONS

1100*500*900 mm


CERTIFICATION

2006/42/EC - 2006/95/EC / ISO 9001:2008
