Automatic Cage Machine

Features (SGH25-12):
Cage Diameter Range: ∮400-∮2000mm
Max Cage’s Length: 12m
Max Rotating Speed:3.1r/min
Weight:14t

Product Details


Construction concrete Pile cage making machine/Rebar cage welding machine

Features:
Based on requirement of construction, the latitudinal rebar will be inserted intothe sleeves which fixed on the rotating disk, take longitudinal circle wire and welding it on one latitudinal rebar, when the machine driven and the rotating disk rolling, the longitudinal circle wire will be twines around the rebar, when the disk is moving, it is also rotating, then it will be pile cage. It is controlled by programmable logic controller, the power will be offered by servo motor. There are also hydraulic lifting device under the cage for supporting, welding guns can work automatically according to order.

Automatic Cage Welding Machines are designed as unit construction systems which enables our customers to be flexible in considering the individual interests and requirements. A special version of the Automatic Cage Welding Machine producing polygonal reinforcement cages also sells very well. With this machine, reinforcement cages for pillars and supporting beams can be manufactured as well as reinforced concrete elements, foundation piles etc.


CNC PILE CAGE   WELDING MACHINE(Automatic Welding)

CAGE DIAMETER

400mm-2000mm

MAX. CAGE LENGTH

12m(or customized)

CAGE WEIGHT

6000 KG

COIL BAR DIAMETER

5-16 mm

MAIN FRAME BAR DIAMETER

12-40 mm

HYDRAULIC PRESSURE

10 Mpa

RATED POWER

23 KW

L×W×H

28000×8000×33000mm

CERTIFICATION

ISO 9001:2008
