CNC Rebar Double Bending

We are instrumental in providing to our valuable customers excellent quality Vertical Rebar Double Bending Machine which is available with following Features:- 1. Imported PLC and touch screen. 2. Central soft rebar lock. 3. Head-treated plate to be wearable. 4. Bending shaft controlled by...

Product Details


We are instrumental in providing to our valuable customers excellent quality Vertical Rebar Double Bending Machine which is available with following Features:-
1. Imported PLC and touch screen.
2. Central soft rebar lock.
3. Head-treated plate to be wearable.
4. Bending shaft controlled by servo.
5. Moved bending unit and automatic gauge system.
6. High strength rail for long life.
7. Bending &clamping unit to enhance precision.
8. Extensible shaft to bend rebar in bi-direction.
9. Heavy loading shift for large batch material.
10. More rebar bended in one time.
11. Large storage capacity can save more than 100 geometric graphics.
12. More angle in one loop.


Vertical Rebar Bending Center

RATED POWER

15KW

MAX. BENDING SPEED

72°/SEC

AIR PRESSURE

0.8MPA

WEIGHT

3.9T

MAX. BENDING ANGLE

+180°

L*W*H

12000*2000*1500MM

-120°

MAX. LENGTH OF STIRRUP SIDE


10M

ELECTRIC CONSUMPTION

4KW/H

MIN. BENDING SIDE LENGTH

520MM

STEEL BAR DIAMETER

10

12

14

16

20

22

25

BENDING HEAD MOVING SPEED

0.5-2M/SEC

BENDING QUATITY

7

6

5

4

3

2

1
